How long would a trip from the airport to the railway station take?

## Cutting to the chase

Assuming remodelled streets, optimized for light rail, the journey would take about 22 minutes at peak times and 25 minutes off-peak.

The estimated travel time is 19 minutes, plus on average 3 minutes’ waiting at peak times or 6 minutes’ waiting off-peak.

The trip is 9.6 km.

The vehicle acceleration rate is 1.0 m/s^{2}.

The vehicle braking rate is −1.0 m/s^{2}.

The average dwell time at stops is 20s.

## First approximation

The average cruising speed has a big influence on the travel time. The time to travel 800m between stops is about 65s at 60 kph, 72s at 50 kph, and 83s at 40 kph. For light rail running on-street, cities invest in remodelling the street to allow cruising speeds of 50 kph or more, where it is practical to do so.

FIT assumes that Wellington will remodel all streets the light rail vehicles run on, to maximize the cruising speed. This means in many cases removing lanes of traffic or parking, restricting turn movements, closing or redesigning intersections, and where possible, widening and improving the pedestrian footpaths. Stops will be located about every 800m, but in reality will be at convenient nodes or logical locations that best fit the fabric of the city.

As a first approximation, assume Wellington will remodel the streets so that light rail can achieve an average cruising speed of 50 kph for half the line length and 40 kph for the other half. That is, the overall average cruising speed is 44 kph.

This yields an estimated travel time of *under 19 minutes*.

## Second approximation

As a second approximation, we estimate the distance and expected average cruising speed for each leg of the route.

From | To | Distance km | Cruise speed kph |
---|---|---|---|

WRS | Frank Kitts | 0.9 | 43.5 |

Frank Kitts | Te Aro Park | 0.6 | 50.0 |

Te Aro Park | Pukeahu | 0.9 | 50.0 |

Pukeahu | King Street | 0.6 | 40.0 |

King Street | Hospital | 0.6 | 50.0 |

Hospital | Newtown | 0.7 | 37.5 |

Newtown | Zoo | 0.7 | 40.0 |

Zoo | Kilbirnie | 0.9 | 60.0 |

Kilbirnie | Sports Centre | 0.6 | 40.0 |

Sports Centre | Miramar | 1.6 | 40.0 |

Miramar | Airport | 1.5 | 40.0 |

This also yields an estimated travel time of *19 minutes*, at an average cruising speed of 43 kph.

During detailed route design it may be feasible to remodel the streets in a way that achieves higher cruising speeds than estimated and hence a shorter travel time. On the other hand, if Wellington decides not to optimize the streets for light rail, the travel time may be longer. A more accurate travel time estimate depends on route design detail not available at this time.

## Equations of motion

To compute the time spent accelerating to and braking from the cruising speed:

*v* = *v*_{0} + *a t*

To compute the time spent at cruising speed between stops:

*s* = *s*_{0} + *v*_{0} *t* + ½ *a t*^{2}

*a* = *0*

To compute the distance travelled while accelerating and braking (and therefore the distance travelled at cruising speed):

*v*^{2} = *v*_{0}^{2} + 2 *a* (*s* − *s*_{0})

Applying the equations of motion to compute the estimated travel time for a journey from the airport to railway station is left as an exercise for the reader.

In a graph of speed *ds ∕ dt* (y-axis) as a function of time (x-axis), the area under the curve is the distance travelled:

∫ *ds* = ∫ *f(t) dt*
